CRANE & SOIL STABILIZING RIG
Lattice boom type Crawler cranes

NISSHA DH-series
NISSHA DH-series ( EPOCA-Nick name ) crawler mounted cranes are divided into two different series of a lifting crane purpose (Three models: DH500-6, DH650-6, DH800 ) and a heavy duty version ( Two models: DH700 and DH900 ).
Applications: ① Normal crane : Lifting
② Heavy duty crane: Grabbing/excavating
Fleet of
Crawler cranes   		Normal crane: : 50, 65, 80 ton
Heavy duty : 70, 90ton
Brief specifications    Full-hydraulic drive, self-propelling, Moment limiter, Over-hoisting prevention devices.
Lattice boom with main and auxiliary book blocks
Brief specifications

Full-hydraulic drive, self-propelling, Moment limiter, Over-hoisting prevention devices.
Lattice boom with main and auxiliary book blocks
DH 500 -6 D
DH 500 -6 D
Heavy Duty ( High line pull )
Minor changed
Rated lifting capacity ; 50 tons
Dynamic Hercules series

Fleet of DH series crawler cranes
(Crick underlined parts for getting more information)
The right is reserved to change the specifications without notice.
Please contact NISSHA Representatives to get up to date data.

Model

DH500-6

DH650-6

DH800

DH700D

DH900D
Photos

Specifications

 　 　 PPT-DH800 Features.pdf 477kb 　 　

Lifting load (ton) x radius :(m)

50t x 4.0

65t x 4.0

80t x 4.0

70t x 4.0

90t x 4.0
Basic boom length:(m)

10

10

13

10

13
Maximum boom length :(m)

52

55

58

46

55
Maximum boom + jib length :(m)

43 + 18

46 + 18

49 + 22

-

46m + 16
Main rope speed, High/low(m/min)

Line pull (ton)

109～76/38

6.6

109～76/38

6.6

121～56/28

12

100～68/34

10

100～68/34

10
Aux. rope speed, High/low (m/min)

Line pull (ton)

109～76/38

6.6

109～76/38

6.6

121～56/28

12

100～68/34

10

100～68/34

10
Third rope speed, High/low(m/min)

-

-

-

(43)

(43)
Swing speed rpm

2.7

2.7

3.4

3.4

 3.4
Travel speed (km/h)

1.4

1.4

1.0/1.5

1.4

 1.2
Graudeability (%): Base machine

40

40

40

40

 40
Engine Output/speed (PS/rpm)

180/2100

180/2100

250/2100

250/2100

 250/2100
Weight /base boom, Hook block

50.0 ton

63.7 ton

81.9 ton

68.9 ton

 82.6 ton
Average bearing pressure(kg/cm2)

0.69

0.82

0.90

0.88

 0.94

　
